Fig.07.02
Gear Box
Provides a 90° change of direction for the control of valves in systems that must be operated remotely.
sizes2SHIP OUTFITTING EQUIPMENT AND ACCESSORIES
Configuration
Enter a quantity to add it.
Technical dimensions
| Size | dmm | Lmm | L1mm | L2mm | L3mm | L4mm | Weightkg |
|---|---|---|---|---|---|---|---|
| Küçük | 16 | 155 | 170 | 38 | 97 | 125 | 4.5 |
| Büyük | 25 | 215 | 233 | 68 | 142 | 173 | 9.5 |
Scroll the table sideways to see every dimension.
Material list
| No | Part | Material |
|---|---|---|
| 1 | BODY | GGG 40.3 |
| 2 | STEM | 1040 |
| 3 | PIN | 1045 |
| 4 | BEARING | DIN 625-6004 |
| 5 | BEARING | DIN 625-6003 |
| 6 | OIL SEAL | NBR |
Standards
- Material
- TS EN 1563
Applications
Remotely operated valve systems
