Fig.03.16
Pipe Coupling
Used in ballast circuits, fire circuits and electric cable circuits. Materials are hot-dip galvanized against rust.
DN50–300sizes9PIPES – FLANGES AND PIPE FITTINGS
Configuration
Enter a quantity to add it.
Technical dimensions
| Size | Amm | Dmm | Lmm | L1mm | Weightkg |
|---|---|---|---|---|---|
| DN 50 | 120 | 61 | 170 | 100 | 2.45 |
| DN 65 | 142 | 78 | 200 | 120 | 3.55 |
| DN 80 | 167 | 92 | 200 | 130 | 5.2 |
| DN 100 | 198 | 117 | 220 | 130 | 7.1 |
| DN 125 | 226 | 142 | 230 | 150 | 10.75 |
| DN 150 | 258 | 172 | 230 | 150 | 13.1 |
| DN 200 | 328 | 223 | 250 | 160 | 21.4 |
| DN 250 | 390 | 276 | 280 | 175 | 28.45 |
| DN 300 | 446 | 327 | 310 | 195 | 46.7 |
Scroll the table sideways to see every dimension.
Material list
| No | Part | Material |
|---|---|---|
| 1 | BODY | RG5(CuSn5)RG10(CuSn10) |
| 2 | GASKET | NITRILE |
| 3 | FLANGE | GGG 40.3GSC 25 |
Specifications
Safe working temperature+10/+80°C
Standards
- Dimension
- DIN 87151
- Material
- DIN 2448
Applications
Ballast circuitsFire linesElectric cable circuits
