Fig.03.32
Bronze Angle Valve
Used as the main isolating valve in Kingston (sea water) lines, overboard discharges, fuel lines, bilge suctions and forepeak suctions. The cover carries an open/closed indicator and a bronze bearing.
DN15–80sizes8JIS STANDARD VALVES
Configuration
Enter a quantity to add it.
Technical dimensions
| Size | Amm | L1mm | H1mm | Mmm | Weightkg |
|---|---|---|---|---|---|
| DN 15 | 95 | 65 | 91 | 60 | 2.1 |
| DN 20 | 105 | 70 | 106 | 80 | 2.7 |
| DN 25 | 115 | 75 | 112 | 80 | 3 |
| DN 32 | 140 | 90 | 128 | 90 | 4.6 |
| DN 40 | 150 | 100 | 145 | 100 | 6 |
| DN 50 | 165 | 105 | 164 | 120 | 8 |
| DN 65 | 185 | 115 | 226 | 160 | 12 |
| DN 80 | 200 | 125 | 248 | 200 | 14 |
Scroll the table sideways to see every dimension.
Material list
| No | Part | Material |
|---|---|---|
| 1 | BODY | RG5(CuSn5)RG10(CuSn10) |
| 2 | COVER | RG5(CuSn5)RG10(CuSn10) |
| 3 | STEM | RG5(CuSn5)RG10(CuSn10) |
| 4 | COVER NUT | MS58(CuZn40Pb2) |
| 5 | HANDWHEEL | Aluminum(Etial 160) |
| 6 | DISC | RG5(CuSn5) |
| 7 | GASKET | KLINGRIT(NON ASBESTOS) |
| 8 | PACKING | PFTE |
Specifications
Working temperature-10/+120°C
Standards
- Dimension
- DIN 87151
Applications
Kingston (sea water) linesOverboard dischargesFuel linesBilge suctionsForepeak suctions
